The firmware is available in several languages and can be customised by request. The instrument firmware is also upgradable via USB.

Viscosity meter software#

USB connection to external PC with free measurement Windows-based software (in English)

Simple automated cone calibration using NIST standard oilsĪutomated temperature calibration (additional equipment required)īetter than 1% of span using standard calibration oilsĨ5-240VAC 50/60 Hz single phase universal power, 150 watts Precise beryllium-copper spring-based torque measurement Integrated stick mouse for software control Piezo Push-to-Read button unaffected by contaminants, standard push button as an option Digital speed control typically better than 0.02 RPMĢ Poise, 5 Poise, 10 Poise, 20 Poise, 40 Poise, and 100 Poiseġ0☌ to 100☌ (Model REL0100) and ambient to 230☌ with variable temperatures (Model REL0230), both ranges are available with variable temperatures having a resolution of 0.1☌ and control typically +/- 0.1☌ Variable 5 to 900 rpm in integer steps or 5 to 90 RPM in 0.1 RPM steps (software selectable mode). Designed to withstand use in rugged manufacturing environments.High-quality, value-for-money product manufactured to BS EN ISO2884-1:2006.NµLine can be calibrated to operate with multiple cone sizes in the same machine.Free cone of choice with all new machines, with easy self-calibrating routines for quick and easy set-up.The viscometer is pre-calibrated, certificated, and ready to use straight out of the box.The PC Interface software allows users to analyse and record results and run shear rate or time sweeps.Instrument range, plate temperatures, and viscosity reading with selectable units, all software displayable.

Low-speed mode with speeds of 5-90 RPM in 0.1 RPM increments.Variable speed settings: 5 RPM in integer increments up to 900 RPM.NµLine® viscometers are manufactured at the ATAC factory in the United Kingdom.

Viscosity meter manual#

A Quick Start Guide and an Operational & Maintenance Manual (Electronic Version Optional).Complete PC Interface Software (Windows compatible, in English) at no extra cost.Free cone of your choice, fitted with the viscometer and a 5ml calibration oil sample.The instrument is easily cleaned, and samples may be tested in 60 to 120 seconds, depending upon the material.Įach instrument is ready to use straight out of the box and delivered with the following: Operation is simple, with easy-to-use navigation throughout the measurement process.

Viscosity meter windows 7#

Its capabilities are enhanced by new intuitive Windows-based software, compatible with Windows 7 and higher, which takes on board many of the additional rheological features that customers have requested while still maintaining the historical foundations of the original ICI Cone & Plate instruments, on which the NµLine® Cone & Plate technology is based.

High-temperature Model REL0230: ambient to 230☌ variable temperature range (no cooling).

Low-temperature Model REL0100: 10☌ to 100☌ variable temperature range with sub-ambient capabilities.

Readings can be taken at variable shear rates, with multiple speeds and at temperatures between 10☌ and 230☌. NµLine® is a self-calibrating, highly adaptable ‘At-Line’ instrument designed to be a cost-effective and robust option between delicate laboratory instruments and the lower-end ‘Go-No-Go’ type viscosity measurement devices currently on the market. The rugged design ensures that it meets the high demands of modern manufacturing environments with both reliability and performance standards. The NµLine® Cone & Plate viscometer was developed based on the RELL Analogue viscometer, with process applications in the paint, varnish, inks, resins, food, bitumen, oil, adhesives, and pharmaceutical industries.
